Chapter 1
Get to Know About Your Extender
1. 2. 1. LED Explanation
You can check the extender’s working status by following the LED Explanation table.
Name Status Indication
(Power)
On/Off The extender is on or off.
Blinking The system is starting up or firmware is being upgraded.
(Signal)
Solid blue
The extender is connected to your router’s wireless
network and is in a suitable location.
Solid red
The extender is receiving a weak signal. Try relocating it
closer to your router.
Blinking WPS connection is in progress.
Off No wireless connection is established.
2.4G On/Off
The extender is connected or not connected to the
2.4GHz wireless network of your router.
5G On/Off
The extender is connected or not connected to the 5GHz
wireless network of your router.
1. 2. 2. Button Description
The buttons are on the side panel of the product.
Button Description
/ / WPS
Press the WPS button on your router, and immediately press this
button on the extender for 1 second. The
LED of the extender
should change from blinking to solid on, indicating successful WPS
connection.
RESET Use a pin to press the button for 1 second to reset the extender.

TP-Link RE705X Specifications

General

Antenna type	External
Product type	Mesh router
Reset button	Yes
Product color	White
Antennas quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Security algorithms	WEP, WPA, WPA2, WPA3
Networking standards	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11g
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Ethernet LAN (RJ-45) ports	1
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	12.6 W
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth	46 mm
Width	97 mm
Height	158 mm
Package depth	125 mm
Package width	202 mm
Package weight	430 g
