-134-
Figure 4-7 IPsec Policy
Tips:
For the VPN Router in the remote branch office, the IPsec settings should be consistent with the
Router in the headquarters. The Remote Gateway of the remote Router should be set to the IP
address of the Router in the headquarters.
After the IPsec VPN tunnel of the two peers is established successfully, you can view the connection
information on the VPN→IPsec→IPsec SA page.
Figure 4-8 List of IPsec SA
4.3.2.2 PPTP VPN Setting
 IP Address Pool
Choose the menu VPN→L2TP/PPTP→IP Address Pool to load the following page. Enter the Pool
Name and the IP Address Range as the following figure shown. Click the <Add> button to apply.
