Omada Stackable L3 Managed Switch
01Introduction
Chapter 1 Introduction
1.1 Product Overview
Designed for workgroups and departments, TP-Link Omada Stackable L3 Managed Switch provides
wire-speed performance and abundant L2 and L3 management features. It provides a variety of service
features and multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible solutions for
a variable scale of networks. Static Routing, RIP, OSPF, and ECMP come with abundant Layer 3 routing
protocols that support a scalable network. Physically stacking for built-in redundancy and performance.
Redundant power supplies and fans make it an ideal choice for reliable networking architecture. VRRP
allows a group of switches to dynamically back up each other. ERPS supports rapid protection and
recovery in a ring topology. ACL, 802.1x and Dynamic ARP Inspection provide robust security strategies.
QoS and IGMP snooping/filtering optimize voice and video application. Link aggregation (LACP) increases
aggregated bandwidth, optimizing the transport of business critical data. SNMP, RMON, WEB and CLI Log-
in bring abundant management policies. TP-Link Omada Stackable L3 Managed Switch integrates multiple
functions with excellent performance, and is friendly to manage, which can fully meet the need of the users
demanding higher networking performance.
SG6428XHP/SG6654XHP is also a Power Sourcing Equipment (PSE*). The RJ45 ports that support Power
over Ethernet (PoE*) function can automatically detect and supply power to those powered devices (PDs*)
complying with IEEE 802.3af and IEEE 802.3at.
*PSE: a device (switch or hub for instance) that provides power through an Ethernet cable.
*PoE: This technology describes a system to transmit electrical power, along with data, to remote devices
over standard twisted-pair cable in an Ethernet.
*PD: a device powered by a PSE and thus consumes energy. Examples include powering network cameras,
wireless LAN access points, IP telephones, network hubs, embedded computers etc.
1.2 Appearance
■
Front Panel
(The gures are for demonstration only. They may dier from your actual products. )
The front panel of SG6428X is shown as the following figure.
The front panel of SG6428XHP is shown as the following figure.
Mode Selection
Button
Management
Port
LED
Console Port
(Type-C/RJ45)
USB2.0 Port
1G RJ45 Port
SFP+ Slot
LED
Mode Selection
Button
Management
Port
LED
Console Port
(Type-C/RJ45)
USB2.0 Port
1G RJ45 Port
SFP+ Slot
LED
