TD-8616 ADSL2+ Modem User Guide
21
Appendix A: Specifications
General
Standards and Protocols
ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, G.992.4, ITU
G.992.5, IEEE 802.3, IEEE 802.3u, TCP/IP, HTTP
Safety & Emission FCC, CE
Ports
1 10/100M Auto-Negotiation RJ45 port（Auto MDI/MDIX)
1 RJ11 port
LEDs Power, LAN, ADSL, Internet
Network Medium
10Base-T: UTP category 3, 4, 5 cable
100Base-TX: UTP category-5
Max line length: 6.5Km
Data Rates
Downstream: Up to 24Mbps
Upstream: Up to 3.5Mbps（With Annex M enabled）
System Requirement
Internet Explorer 5.0 or later, Netscape Navigator 6.0 or later
Win 9x/ME/2000/XP/Vista
Physical and Environment
Working Temperature 0℃ ~ 40℃
Working Humidity 10% ~ 90% RH (non-condensing)
Storage Temperature -40℃ ~ 70℃
Storage Humidity 5% ~ 90% RH (non-condensing)
