TD-8817 ADSL2+ Ethernet/USB Modem Router User Guide
35
Step 3: Select the application you want from drop-down list, then the protocol and port number
will be added to the corresponding field automatically, you only need to configure the IP
address for the virtual server; If the application list does not contain the service that you
want, please configure the Port number, IP Address and Protocol manually.
Step 4: After that, click SAVE to make the entry take effect.
Other operations for the entries are as follows:
Enter the index of assigned entry, click the DELETE button to delete the entry.
Click the BACK button to return to the previous screen.
Click the CANCEL button to cancel the configuration which is made just now.
4.4.3.3. IP Address Mapping
Choose “Ad
vanced Setup→NAT”, select Multiple in Number of IPs. Click IP Address Mapping,
then you can configure the Address Mapping Rule in Figure 4-27. The IP Address Mapping is for
those VCs th
at configured with multiple IPs. The IP Address Mapping rule is per-VC based (only
for Multiple IPs' VCs).
Figure 4-
26
Figure 4-27
Rule Index: Select the Address Mapping Rule index for this VC. You can specify 8 rules in
maximum.
