TP-Link TF-3200 User Manual

TF-3200 10/100Mbps PCI Network Adapter
4
Figure 2-2 Found New Hardware Wizard in Windows Vista
2.2 Software Installation
This section will guide you through the installation procedures for Windows XP, Windows 7, and
Windows Vista. Please carefully follow the steps.
2.2.1 For Windows XP
1. Insert the TP-LINK Resource CD into the CD-ROM drive.
2. Right-click the icon My Computer on the desktop, and then click Manage.
Figure 2-3

TP-Link TF-3200 Specifications

General

Full duplex	Yes
Maximum data transfer rate	100 Mbit/s
Compliance industry standards	IEEE 802.3, 802.3u, 802.3x
Supported data transfer rates	10/100 Mbps
Connectivity technology	Wired
Compatible operating systems	Win NT, XP, VISTA Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE
