Choos n see the submenus under the main menu: Time
ls→Time Settings”, and then you can configure the time on the
e menu “System Tools”, and you ca
Settings, Diagnostic, Firmware Upgrade, Factory Defaults, Backup & Restore, Reboot,
Password, System Log and Statistics. Click any of them, and you will be able to configure the
corresponding function. The detailed explanations for each submenu are provided below.
5.16.1 Time Settings
Choose menu “System Too
following screen.
Figure 5-78 Time Settings
¾
Time Zone - Select your loca n list.
the NTP Server I or NTP
ck the box to enable the Daylight Saving function.
week in
l time zone from this pull dow
¾ Date - Enter your local date in MM/DD/YY into the right blanks.
¾ Time - Enter your local time in HH/MM/SS into the right blanks.
¾ NTP Server I / NTP Server II - Enter the address or domain of
Server II, and then the Router will get the time from the NTP Server preferentially. In
addition, the Router built-in some common NTP Servers, so it can get time automatically
once it connects the Internet.
¾ Enable Daylight Saving - Che
¾ Start - The time to start the Daylight Saving. Select the month in the first field, the
the second field, the day in the third field and the time in the last field.
-169-

TP-Link TL-MR3040 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Rack mounting	No
Frequency band	2.4 GHz
Frequency range	2.4 - 2.4835 GHz
USB ports quantity	2
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	1
Routing protocols	IP
Supported network protocols	Dynamic IP, Static IP, PPPoE, BC, L2TP, PPTP
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-PSK, WPA2-PSK
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	15 - 40 °C
Operating relative humidity (H-H)	0 - 75 %
Cables included	LAN (RJ-45), USB
Product color	White
LED indicators	LAN, Power, WLAN

Weight and Dimensions

Depth	62 mm
Width	100 mm
Height	16 mm
Weight	94 g
