TL-MR3040 Portable 3G/3.75G Battery Powered Wireless N Router
¾ If the connection type detected is Static IP, the next screen will appear as shown in
Figure 3-13.
Figure 3-13 Quick Setup - Static IP
z IP Address - This is the WAN IP address seen by external users on the Internet
(including your ISP). Enter the IP address into the field.
z Subnet Mask - The Subnet Mask is used for the WAN IP address, it is usually
255.255.255.0.
z Default Gateway - Enter the gateway IP address into the box if required.
z Primary DNS - Enter the DNS Server IP address into the box if required.
z Secondary DNS - If your ISP provides another DNS server, enter it into this field.
2. Click Next to continue, the Wireless settings page will appear as shown in Figure 3-14. Set
your wireless parameters. It’s recommended that you edit the following two items, and then
click Next.
1) Create a unique and easy-to-remember Wireless Network Name.
2) Select WPA-Personal/WPA2-Personal under Wireless Security and enter a
password in the field.
-15-
