Unmanaged/Easy Smart Rackmountable Switches
Introduction
■
Rear Panel
The rear panel is shown as the following figure. Here we take TL-SG1016PE as an example.
Figure 1-19 Rear Panel
Grounding TerminalPower SocketKensington Security Slot
Kensington Security Slot
Secure the lock (not provided) into the security slot to prevent the device from being stolen.
Note:
Only TL-SG1016PE and TL-SG1218MPE has a kensington security slot.
Grounding Terminal
The switch already comes with lightning protection mechanism. You can also ground the switch through
the PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed information, refer to the
Lightning Protection Guide from the Related Documents of our website:
https://www.tp-link.com/us/conguration-guides/lightning_protection_guide
Power Socket
Plug the female connector of the power cord directly into the power socket and plug the male connector
into an AC outlet. Make sure that the voltage of the power supply meets the requirement of the input
voltage (100–240 V~ 50/60 Hz).
Caution:
You should use the provided power cord.
