TP-Link TL-SG3428X User Manual

JetStream L2/L2+ Managed Switch
02 Introduction
The front panel of TL-SX3016F is shown as the following figure.
LED
Console Port
(USB/RJ45)
1G
RJ45 Port
SFP+ Slot
The front panel of TL-SG3210 is shown as the following figure.
1000Mbps
10/100Mbps
Activity
10/100/1000M
1000Mbps
100Mbps
Activity
SFP
2
1
4
3
6
5
8
7
10
9
PWR
SYS
10/100/1000M
TL-SG3210
L2+ Managed Switch
SFP
LED Console Port
(RJ45/USB)
1G RJ45 Port SFP Slot
The front panel of TL-SG3210XHP-M2 is shown as the following figure.
LED Console Port
(RJ45/USB)
2.5G
RJ45 Port
SFP+ Slot
The front panel of TL-SG3428 is shown as the following figure.
LED Console Port
(USB/RJ45)
1G
RJ45 Port
SFP Slot
24-Port Gigabit L2+ Managed Switch
with 4 SFP Slots
The front panel of TL-SG3428MP is shown as the following figure.
LED Console Port
(RJ45/USB)
1G
RJ45 Port
SFP Slot
The front panel of TL-SG3428X is shown as the following figure.
LED Console Port
(USB/RJ45)
1G
RJ45 Port
SFP+ Slot
24-Port Gigabit L2+ Managed Switch
with 4 10GE SFP+ Slots

TP-Link TL-SG3428X Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
Stackable	-
Form factor	1U
Product color	Black
Number of fans	0 fan(s)
Console port	RJ-45/micro-USB
Power connector	AC-in jack
SFP+ module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
IPv4 routes	48
Number of VLANs	4000
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Ethernet LAN data rates	10, 100, 1000 Mbit/s
DHCP features	DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
Authentication	Guest VLAN, MAC-based authentication, Port-based authentication
Authentication type	AAA, RADIUS, TACACS+
Jumbo frames	9000
Forwarding rate	95.23 Mpps
MAC address table	16000 entries
Packet buffer memory	12 MB
Heat dissipation	80.353 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	250 mm
Package width	528 mm
Package height	80 mm
Package weight	2690 g
Cables included	LAN (RJ-45)
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	23.6 W
Harmonized System (HS) code	85176990
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 ping, IPv6 tracert

Weight and Dimensions

Depth	180 mm
Width	440 mm
Height	44 mm
