TL-WR743ND 150Mbps Wireless AP/Client Router
- 128 -
Figure A-8 Remote Management
Note:
If the above configuration takes effect, configure to the Router by typing 192.168.0.1:88
(the Router’s LAN IP address: Web Management Port) in the address field of the Web
browser.
3) Log in to the Router, click the “Forwarding” menu on the left of your browser, and click
the "Virtual Servers" submenu. On the "Virtual Servers" page, click Add New…, then
on the “Add or Modify a Virtual Server” page, enter “80” into the blank next to the
“Service Port”, and your IP address next to the “IP Address”, assuming 192.168.0.188
for an example, remember to Enable and Save.
Figure A-9 Virtual Servers
