61
Second
Connection
If your ISP provides an extra Connection type such as Dynamic/Static IP
to connect to a local area network, activate this secondary connection.
'LVDEOH The Secondary Connection is disabled by default, so there is
PPPoE connection only. This is recommended.
'\QDPLF,3 Use dynamic IP address to connect to the local area
network provided by ISP.
6WDWLF,3 Use static IP address to connect to the local area network
provided by ISP.
IPv6 Enable or disable the IPv6 function. If the IPv6 function is enabled, the
device will obtain a WAN IPv6 address. Select a method for the device to
obtain the WAN IPv6 address according to the information provided by
your ISP.
• SLAAC
Select SLAAC and the device will obtain the WAN IPv6 address
automatically.
• '+&3Y
Select DHCPv6 and the device will obtain the WAN IPv6 address
automatically.
MTU Size Specify the MTU size. The default MTU (Maximum Transmission Unit)
size is 1480 bytes, which is usually appropriate. For some ISPs, you need
modify the MTU. This should not be done unless your ISP told you to.
This number should be an integer between 576 and 2026.
Service Name Specify the Service Name provided by your ISP. Keep it empty if your
ISP doesn't provide the name.
AC Name Specify the AC Name provided by your ISP. Keep it empty if your ISP
doesn't provide the name.
Detect Internal Specify the Detect Interval. The default value is 0. Input the value
between 0 and 120. The device will detect Access Concentrator online
every interval seconds. If the value is 0, it means not detecting.
Use
ISP-specified IP
If your service provider provides you with an IP address along with the
user name and password, Enable "Use ISP-specified IP" and enter the IP
address.
