3533
d) Press SETUP/MEM Key
PAGE EDIT SAVE LOAD EXIT
UP
F1 F2 F3 F4 F5
F1: Page Up, Down; Select Memory Location
(0,1,2,3,4,5,6,7 Page)
F2: New Edit (Range, Contrast, D Mode, Baud Rate, etc.)
F3: Save the present setup status
F4: Load and setup from selected Memory
e) EDIT Press
NEXT
EXIT
NEXT: Menu selection
, : Mode level and function selection.
f) Adjusting REL% and COMP reference value is as follows
1. Enter the REL% key COMP mode by pushing PROG key
2. Push the REL% key(F2) to adjust REL% reference value
and then push EDIT key(F4).
3. Set the digit by right and left direction key and set the
figure by up to down direction key and then push the
EXIT key.
4. Enter the COMP mode by pushing F3 key and push the
EDIT key(F4).
5. Set the digit by right and left direction key and set the
figure by up and down direction key and then push the
EXIT key(HI,LO,setting).
6. Push the RGE key and SETUP/MEM key.
7. Save the adjusted value with page up key(F1) to memory
page.
To Next Page
