DMX-512 Channels
The Tracker 575 Spot requires 17 channels of DMX.
Channel Function
1 Pan Coarse Movement
2 Pan Fine Movement
3 Tilt Coarse Movement
4 Tilt Fine Movement
5 Movement Speed Pan/Tilt
6 Control Reset/Lamp
7 Focus
8 Color Wheel 1
9 Color Wheel 2
10 Prism
11 Fixed Gobo Wheel
12 Rotating Gobo Wheel
13 Gobo Rotation & Index
14 Iris
15 Zoom
16 Shutter
17 Dimmer
CH 1-4 : Pan / Tilt Movement
The Pan and Tilt motors use a position feedback system. If the position of either is
disturbed, the fixture will correct automatically. The Pan and Tilt Menu Modes can be
used to alter the default direction of movement. Movement speed is either automatically
determined by the fixture or manually set using Channel 5 Pan/Tilt Movement Speed.
Pan range is 530° of movement. Tilt range is 280° of movement.
CH 1 – Pan Coarse Movement (530°)
CH 2 – Pan Fine Movement
CH 3 – Tilt Coarse Movement (280°)
CH 4 – Tilt Fine Movement
DMX Value Function
0 – 255 Movement - Minimum to Maximum
