CH 5 : Movement Speed Pan/Tilt
When set to zero (0) the fixture automatically determines the Pan/Tilt speed. Other
values are used to set the movement speed manually.
CH 5 – Movement Speed Pan/Tilt
DMX Value Function
0 Auto Speed
1-255 Fixed Speed - Fast to Slow
CH 6 : Control Reset/Lamp
Fixture reset and Lamp On/Off control is accessed from a single channel. The “No
Function” values provide buffer zones between functions and are not values to which the
channel should be set. In the case of noisy faders or unintentional movement, the buffers
will prevent slight variations in value to toggle Lamp states or start a fixture Reset.
CH 6 – Control Reset/Lamp
DMX Value Function
0-127 No Function
128-139 RESET then Lamp ON (3 second delay)
140-229 No Function
230-239 Lamp OFF (3 second delay)
240-255 No Function
CH 7 : Focus
Adjusts the focus of the projected image. When using both Gobo wheels, varying the
Focus can create many interesting effects.
CH 7 – Focus
DMX Value Function
0-255 Focus – Near to Far
