Tracker PRO Series - Color Wheel 2 and Prism Effects; Color Wheel 2 Functions; Prism Effect Control

17
CH 9 : Color Wheel 2
Color Wheel 2 holds 7 solid colors plus CTO and CTB color shifts. Bi-Color effects can
be set and used in conjunction with Color Wheel 1 to create many color combinations.
CH 9 – Color Wheel 2
DMX Value Function
0-12 Open
13-25 Open / Lt. Red
26-38 Lt. Red
39-51 Lt. Red / Lt. Yellow
52-64 Lt. Yellow
65-77 Lt. Yellow / Lt. Purple
78-90 Lt. Purple
91-103 Lt. Purple / Lt. Green
104-116 Lt. Green
117-129 Lt. Green / Lt. Orange
130-142 Lt. Orange
143-155 Lt. Orange / Blue
156-168 Blue
169-181 Blue / Lt. Blue
182-194 Lt. Blue
195-207 Lt. Blue / CTO (3200°K)
208-220 CTO (3200°K)
221-233 CTO (3200°K) / CTB (6000°K)
234-246 CTB (6000°K)
247-255 CTB (6000°K) / Open
CH 10 : Prism
The Prism effect uses a 3 facet prism to create multiple beams. The effect can be
rotated in either direction at variable speeds.
CH 10 – Prism
DMX Value Function
0-4 Open
5-127 Prism w/ Rotation – CW, Slow to Fast
128-132 Prism w/o Rotation
133-255 Prism w/ Rotation – CCW, Slow to Fast
