10
x 1
6
3
2
1
7
5
B
A
x 6
x 6
ASSEMBLING YOUR GRILL
READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING
THE APPLIANCE
E
x 2
C
x 4
D
x 4
NOTE: Handle bolts, washers, and Mica washers are shipped
pre-installed on the handle, and should be removed for assembly.
PART DESCRIPTION PART DESCRIPTION
1 GRILL LID 5 GREASE BUCKET
2 LID HANDLE 6 GRILL BODY
3 PORCELAIN-COATED GRILL GRATE 7 FEET WITH CAPS
4 GREASE DRIP TRAY
4
Shape may vary.
