Trailer Vision Digi-Max2 - Product Specifications

17
PRODUCT SPECIFICATION
Camera
Image Sensor
Type: 1/4” CMOS
Resolution: 640*480
Optical
Lens Type: Glass
Lens Focal Length: 2.5MM
View Angle: Horizont al:87°±2°; Vertical:62°±2°
Night Vision
Total IR LED: 10 PCS
LED Angle: 120°
LED Wave Length: 850nm
EDS Activate LUX: 1-8LUX
Identified Range: 5-8m
Tranceiver
Frequency: 2.402-2.480GHZ
Modulation: GFSK
Transmission Power: 14±2DBm
Antenna Gain: 3dBi Ant
Communication distance: 200M
Power Source
Power Supply: DC 12-24V
Current Consumption: IR ON:220mA; IR OFF:150mA
Waterproof IPxx IP66
Monitor
LCD Panel
Size˖ 7.0ͳ
Resolution˖
480*234
Luminance:
200cd/΃
Back Light˖
LED
Transceiver
Frequency: 2.405-2.480GHZ
Modulation : GFSK
Sensitivity˖
-82DBm
TV Format NTSC/PAL
Video
Compression˖ MPEG-4
Resolution˖
640*480
Video Output Level˖
1Vp-p/75ohm
Frame Rate˖
12-25 FPS
LCD View Angle
Up /Down: 130°
Left/Right: 140°
Interface DC IN
12-24V
