5
Using the trigger cable:
Utilising the trigger cable enables the Channel 1 camera to be
automatically displayed when reverse gear etc. is engaged.
1. Connect the trigger cable ring-shaped connectors to the fuse/
electrical circuit of the reversing lights.
2. Connect the other end of the trigger cable to the monitor.
3. Turn on the monitor and select reverse gear (with ignition turned on).
4. The screen should display the image of the vehicle rear view
automatically. If it doesn’t, please refer to the 'Pairing Camera(s)' section, to
pair the camera to the monitor.
Note: If [NO SIGNAL] is displayed on the monitor, at any time while
reversing, immediately stop the vehicle, until the image is displayed, or it
is safe to continue.
With battery pack (available separately):
1.
Attach the camera to
the battery.
2. Fix the camera and the battery to the vehicle.
3. Press the power button
, on the battery pack, to power the camera.
