Trane Technologies 4TCC4036E1000A - Product Specification

18-EB39D1-1A-EN
5
Product Specification
MODEL 4TCC4024 4TCC4030 4TCC4036 4TCC4042 4TCC4048 4TCC4060
RATED Volts/PH/Hz 208–230/1/60
Performance Cooling BTUH
(a)
23200 28000 36400 40000 46000 57500
Indoor Airflow (CFM)
785 880 1215 1450 1625 1770
Power Input (KW)
1.94
2.21 3.17 3.53 4.20 4.98
EER2/SEER2 (BTU/Watt-Hr.)
(b)
11.0 / 13.40
10.80 / 13.40 11.0 / 13.40
Sound Power Rating [dB(A)]
(c)
66.6 70 69.3 74.6 72.5 73.2
POWER CONN. — V/Ph/Hz 208–230/1/60
Min. Brch. Cir. Ampacity
(d)
LOCATED ON UNIT NAMEPLATE
Fuse Size — Max. (amps)
25 30 40 45 50 60
Fuse Size — Recmd. (amps)
25 30 40 45 50 60
COMPRESSOR SCROLL
Volts/Ph/Hz 208–230/1/60
R.L. Amps — L.R. Amps
LOCATED ON UNIT NAMEPLATE
OUTDOOR COIL — TYPE SPINE-FIN
Rows/F.P.I 2 / 24
Face Area (sq. ft.)
13.32 13.32 15.49 15.63 20.54 22.99
Tube Size (in.)
3/8
INDOOR COIL — TYPE MCHE
PLATE FIN
Rows/F.P.I 2 / 16
Face Area (sq. ft.)
2.7 2.7 2.7 3.9 3.9 5
Refrigeration Control
EXPANSION VALVE
Drain Conn. Size (in.)
3/4 FEMALE NPT
OUTDOOR FAN — TYPE PROPELLER
DIA. (IN.)
23.4 23.4 23.4 28.25 28.25 28.25
DRIVE/NO. SPEEDS DIRECT / 1
CFM @ 0.0 in. w.g
(e)
2350 2800 3080 3400 3400 4800
Motor — HP/R.P.M 1 / 12 / 810 1/6 /825 1/5 / 825 1/4 / 825 1/4 / 825 1/3 / 825
Volts/Ph/Hz 208–230/1/60
F.L. Amps/L.R Amps
LOCATED ON UNIT NAMEPLATE
INDOOR FAN — TYPE
CONSTANT TORQUE ECM
Dia. x Width (in.)
10.62 X 10.62
Drive/No. Speeds
DIRECT / 4
CFM @ 0.0 in. w.g
(f)
SEE FAN PERFORMANCE TABLE
Motor — HP / R.P.M. 1/3 / 1050 1/2 / 1050 3/4 / 1050 3/4 / 1050 3/4 / 1050 1 / 1050
Volts/Ph/Hz 208–230/1/60
F.L. Amps
LOCATED ON UNIT NAMEPLATE
FILTER / FURNISHED
NO
Type Recommended
THROWAWAY
Recmd. Face Area (sq. ft)
(g)
4 4 4 5.3 5.3 5.3
REFRIGERANT R-410A
Charge (lbs.)
LOCATED ON UNIT NAMEPLATE
CHARGING SPECIFICATIONS
Subcooling
10˚ 8˚ 11˚ 10˚ 10˚ 11˚
(a)
Rated in accordance with AHRI Standard 210/240.
(b)
Rated in accordance with D.O.E. test procedure.
(c)
Sound Power values are not adjusted for AHRI 270–95 tonal corrections.
(d)
Calculated in accordance with currently prevailing Nat’l Electrical Code.
(e)
Standard Air — Dry Coil — Outdoor.
(f)
Standard Air — Dry Coil — Indoor
(g)
Filters must be installed in return air stream. Square footages listed are based on 300 f.p.m. face velocity. If permanent filters are used size per
manufacturer’s recommendation with a clean resistance of 0.05” W.C.
