18-EB40D1-1A-EN
41
Refrigerant Circuit
INDOOR
COIL
EXPANSION
VALVE BU
LB
OUTDOOR
COIL
LPCO
SCHRADER
VALVE LO
EQUALIZER
LINE
SCHRADER VALVE
LIQUID
LIQUID
LINE
DRIER
INDICATES DIRECTION OF
REFRIGERATION FLOW
COMPRESSOR
HPCO
EXPANSION
VALVE
SCHRADER
VALVE HI
