8
18-EB40D1-1A-EN
Determine Unit Clearances
Figure 1. Space on Sides Requirements
Note: The view labeled “Bottom side”
represents the base as viewed looking
up from underneath the unit.
W/ ECONOMIZER W/ ECONOMIZER
BACK SIDE 305 [12] 762 [30] 305 [12] 762 [30]
LEFT SIDE 762 [30] 914 [36] 914 [36] 1067 [42]
RIGHT SIDE 610 [24] - 610 [24] -
FRONT SIDE 1067 [42] - 762 [30] -
BOTTOM
BACK SIDE
LEFT SIDE
RIGHT SIDE
FRONT SIDE
TOP
A HEIGHT OF UNIT - TABLE NEXT PAGE
BB CENTER OF GRAVITY - TABLE NEXT PAGE
CC CENTER OF GRAVITY - TABLE NEXT PAGE
DD -Depth
EE -Width
FF
25 [1]
0
25 [1]
DIMENSIONS mm [Inches]
2 - 3 TON Units 3.5 - 5 TON Units
RECOMMENDED SERVICE CLEARANCE mm [Inches]
CLEARANCE TO COMBUSTIBLE MATERIAL mm [Inches]
0
2 - 3 TON 3.5 - 5 TON
152 [6]
152 [6]
305 [12]
914 [36]
1049.02 [41-5/16]
1240.28 [48.27-27/32]
152 [6]
152 [6]
305 [12]
914 [36]
475.23 [18-23/32]
1125.22 [44-5/16]
1487.17 [58-9/16]
551.43 [21-23/32]
FF
DD
EE
