BAS-SVX44C-EN 25
Configuration Option Setup
Installation Options
Table 7. Installer configuration setup menu
Opt.
No.
Name Def Values/Descriptions Notes
0100
Temperature indication/
Resolution
0 0= °F, 1 degree resolution
1= °F, 0.5 degree resolution
2= °C, 1 degree resolution
3= °C with 0.5 degree
resolution
4= °C with 0.1 degree
resolution
This setting affects indoor temperature display and setpoint
display resolutions. Outdoor temperature display area is
always ±1 resolution for both F and C. Refer to Option 0210.
0110
Clock Format 12 12= 12-hour clock 24= 24-hour clock
0120
Year 11 11–99
Available year range: 2011–2099. This value is updated to the
real time clock after setting. Day of the week is updated
0121
Month 1 •112
This value is updated to the real time clock after setting. Day
of the week is updated automatically.
0122
Day 1 •131
Month dependent: this value is updated to the real time clock
after setting. Day of the week is updated automatically.
0125
Daylight Savings 2 •0= Disabled
1= US (1987), changeover at
2:00am
2= US (2007), changeover at
2:00am
3= Europe, changeover at
1:00am
4= Manual, changeover at
2:00am
0126
0127
0128
0129
Spring Ahead Month
Spring Ahead Day
•Fall Back Month
•Fall Back Day
•03
•01
•11
•01
•01-12
•01-31
•01-12
•01-31
Options available only if 0125 is set to 4.
0130
System Selection 8 1= 1H/1C (Conv) 1st Stage
Heat (W), 1st Stage Comp (Y),
Fan (G)
2= 1H/1C (HP) 1st Stage Comp
(Y), Changeover (O/B), Fan (G)
3= 1H (Conv) 1st Stage Heat
(W), without fan
4= 1H (Conv) 1st Stage Heat
(W), Fan (G)
5= 1C (Conv) 1st Stage Comp
(Y), Fan (G)
6= 2H/1C (HP) 1st Stage Comp
(Y), Changeover (O/B),
Auxiliary Heat (W1), Fan (G)
7= 2H/2C (Conv) 1st & 2nd
Stage Heat (W,W2), 1st & 2nd
Stage Comp (Y,Y2), Fan (G)
8= 2H/1C (Conv) 1st & 2nd
Stage Heat (W,W2), 1st Stage
Comp (Y), Fan (G)
9= 1H/2C (Conv) 1st Stage
Heat (W), 1st & 2nd Stage Comp
(Y,Y2), Fan (G)
10= 2H/2C (HP) 1st & 2nd
Stage Comp (Y,Y2), Changeover
(O/B), Fan (G)
11= 3H/2C (HP) 1st & 2nd
Stage Comp (Y,Y2), Changeover
(O/B), Auxiliary Heat (W1), Fan
(G)
0140
Schedule Options 1 0=Non-programmable 1= Programmable
0150
TOD/Economizer Output
(Terminal A)
0 0= Unused
•1= TOD energizes terminal A
during occupied period, not
during unoccupied period.
2= Economizer energizes
terminal A during a call for cool.
TOD is not available in Non-programmable Mode. (Refer to
Option 0140)
0151
Heat Fan Operation 0 0= System controls fan 1= Thermostat controls fan
Only shown for conventional system with heat stages and fan
capability. For heat pump, the fan relay operates with
thermostat control.
0153
Reversing Value O/B 0 0= O/B ON when call for cool 1= O/B ON when call for heat
Only shown for heat pump systems.
0160
Cycles Per Hour (CPH) [First
Stage Compressor]
3 1–5
Only for systems with cool or HP stage. (Refer to Option 0130.)
Selection in this stage changes 2nd stage cool default CPH.
0161
CPH (Second Stage
Compressor)
3 1–5
Only for systems with 2-cool or HP stages. (Refer to Option
0130.)
0162
CPH (First Stage
Conventional Heat)
5 1–10
Only for conventional systems with heat stages. (Refer to
Option 0130.) Selection in this stage changes default CPH of
2nd stage heat.
0163
CPH (Second Stage
Conventional Heat)
9 1–10
Only for conventional systems with two stages of conventional
heat.
0164
CPH for Auxiliary Heat 9 1–10
Only shown for 2H/1C HP or 3H/2C HP systems. (Refer to
Option 0130.)
0165
CPH for Emergency Heat 9 1–10
Only shown for 2H/1C HP or 3H/2C HP systems. (Refer to
Option 0130.)
0170
Continuous Backlight 0 0= Backlight ON time is limited 1= Backlight ON continuously
