BAS-SVX44C-EN 27
Configuration Option Setup
0232
Starting Default Period Occ/
Unocc Definitions
4
If option #0231 is set to 2
Day—Night
• 0= UnOcc—UnOcc
• 1= UnOcc—Occ
• 2= UnOcc—UnOcc
• 3= UnOcc—Occ
•4= Occ—UnOcc
•5= Occ—Occ
•6= Occ—UnOcc
•7= Occ—Occ
• 8= UnOcc—UnOcc
• 9= UnOcc—Occ
•10= UnOcc—UnOcc
•11= UnOcc—Occ
•12= Occ—UnOcc
•13= Occ—Occ
•14= Occ—UnOcc
•15= Occ—Occ
If option #0231 is set to 4
Morn—Day—Evening—
Night
• 0= UnOcc—UnOcc—UnOcc—
Unocc
• 1= UnOcc—UnOcc—Unocc—
Occ
• 2= UnOcc—UnOcc—Occ—
UnOcc
• 3= UnOcc—Unocc—Occ—Occ
• 4= UnOcc—Occ—UnOcc—
UnOcc
• 5= UnOcc—Occ—UnOcc—Occ
• 6= UnOcc—Occ—Occ—UnOcc
• 7= UnOcc—Occ—Occ—Occ
• 8= Occ—UnOcc—UnOcc—
UnOcc
• 9= Occ—UnOcc—UnOcc—Occ
• 10= Occ—UnOcc—Occ—
UnOcc
• 11= Occ—UnOcc—Occ—Occ
• 12= Occ—Occ—UnOcc—
UnOcc
• 13= Occ—Occ—UnOcc—Occ
• 14= Occ—Occ—Occ—UnOcc
• 15= Occ—Occ—Occ—Occ
Occupancy setting can be changed during scheduling for
each period/day.
0233
Days Options for Scheduling
Mode
3 • 0= 1 day; Mo-Su all days share
the same schedule
• 1= 5+1+1 days; Mo-Fr share a
schedule. Sa and Su each have
an independent schedule
• 2= 5+2 days; Mo-Fr share a
schedule. Sa-Su share a
schedule.
• 3= 7 days; Each day has an
independent schedule
Any value toggle of Option 0233 will reset the schedule to the
default values of Options 0231 and 0232, and in addition,
return the schedule to default values.
0240
Heat Temperature Range 90 40–90; 40°F to 90°F 4–32; 4°C to 32°C
Only for systems with heat stage. (Refer to Option 0130.)
0241
Cool Temperature Range 50 50–99; 50°F to 99°F 10–37; 10°C to 37°C
Only for systems with cool stage. (Refer to Option 0130.)
0260
Temperature Display Offset 0 • –3= –3°F (–1.5°C)
• –2= –2°F (–1.0°C)
• –1= –1°F (–0.5°C)
• 0= None
•1= 1°F (0.5°C)
•2= 2°F (1.0°C)
•3= 3°F (1.5°C)
Only applies to control temperature and display temperature
for internal and indoor remote sensor. Does not apply to
outdoor temperature for display.
0270
Extended Fan-on Time Heat 0 0= OFF 90= ninety seconds
This option is not available if Option 0151=0 or if system is cool
only. (Refer to Option 0130.)
0271
Extended Fan-on Time Cool 0 0= OFF 40= forty seconds
This option is not available for systems with heat only. (Refer
to Option 0130.)
0275
Filter Change Indicator 1 •0= OFF
• 1= 30 days
• 3= 90 days
• 4= 120 days
• 6= 180 days
• 12= 365 days
Filter change disabled in OFF. Timer values start on first
power-up or reset of an active filter change icon.
0300
Restore Factory Defaults 0 0= No 1= Yes
No= No action; Yes= Resets all parameters to default except
calendar/daylight savings time/system selection.
Table 7. Installer configuration setup menu (continued)
Opt.
No.
Name Def Values/Descriptions Notes
