Trane 2GN Series User Manual

10 18-GL07D1-4
2GN SPLIT INSTALLER’S GUIDE
PHYSICAL DATA - AIR HANDLER
AIR HANDLER MODEL NUMBER
(REFRIGERANT)
TAMGA0A24 TAMGA0C36 TAMGA0C48 TAMGA0C60
EVAPORATOR
COIL
AIR COIL TOTAL FACE AREA, FT2
[M2]
3.67 [0.34] 5.50 [0.51] 5.96 [0.55] 5.96 [0.55
TUBE OUTSIDE DIAMETER - IN.
[MM]
3/8 [9.52]
NUMBER OF ROWS 3 4
FINS PER INCH 14
SUCTION LINE CONNECTION -
IN. [MM] SWEAT
3/4 [19.05] 7/8 [22.22]
LIQUID LINE CONNECTION - IN.
[MM] SWEAT
3/8 [9.52]
REFRIGERANT R-410A
NOMINAL COOLING CAPACITY - TONS [KW] 2.0 [7.03] 3.0 [10.55] 4.0 [14.07] 5.0 [17.58]
CONDENSATE DRAIN
CONNECTION - (NPT) IN. [MM]
3/4 [19.05]
BLOWER WHEEL SIZE (DIA X W), IN. [MM] 11 X 8 [279 X 203] 11 X 10 [279 X 254]
BLOWER MOTOR TYPE/SPEEDS ECM VARIABLE SPEED
BLOWER MOTOR OUTPUT - HP [W] 1/2 [373] 3/4 [559] 1 [745]
FILTER STANDARD - 1” [51MM] MERV3
DISPOSABLE, IN. [MM]
16 X 20 [406 X 508] 22 X 20 [559 X 508]
ELECTRICAL CHARACTERISTICS (60HZ) 208/230 - 1PH
SHIPPING WEIGHT - LBS. [KG] 127 [57.6] 157 [71.2] 175 [79.4]
OPERATING WEIGHT - LBS. [KG] 116 [52.6] 146 [66.2] 163 [74.9]
LINE SET SIZES
NOTES:
1. “Charge Amount with TAMG Air Handler” column is based on the total charge amount for an TAMG Air Handler + Compressor Section Split.
2. Add charge for length of line set length. Additional charge for R-410A is 0.50 oz. per ft. for 3/8 in. and 1.0 oz. per ft. for 1/2 in. tube.
3. After charge is added, adjustments can be made to get appropriate subcooling and superheat.
4. Longer line sets will reduce capacity and effi ciency of the system as well as adversely effect system reliability due to poor oil return.
5. Line set sizes match split heat pump. Reducing coupling may be required at indoor unit connection.
UNIT
SIZE
AIR
HANDLER
20 FEET 40 FEET 60 FEET
FACTORY
CHARGE
(OZ.)
*CHARGE
AMOUNT
WITH
TAMG AIR
HANDLER
(OZ.)
SUCTION LIQUID SUCTION LIQUID SUCTION LIQUID
026
TAMGA0A24 5/8” OD 3/8” OD 3/4” OD 3/8” OD 3/4” OD 1/2” OD 52 60
038
TAMGA0C36 3/4” OD 3/8” OD 3/4” OD 3/8” OD 3/4” OD 1/2” OD 56 82
049
TAMGA0C48 3/4” OD 3/8” OD 7/8” OD 3/8” OD 7/8” OD 1/2” OD 90 112
064
TAMGA0C60 7/8” OD 1/2” OD 7/8” OD 1/2” OD 1-1/8” OD 1/2” OD 92 111
11/19/12
AIR HANDLER
INDOOR SPLIT
MODEL (DUAL
CAPACITY)
OUTDOOR SPLIT
MODEL (DUAL
CAPACITY)
AIRFLOW (CFM)
ELECTRIC HEAT
SINGLE-PHASE
(KW) 12
ELECTRIC HEAT
3-PHASE (KW) 3
TAMGA0A24 2GN026 2GE026 900 5, 8, 10 10
TAMGA0C36 2GN038 2GE038 1250 5, 8, 10, 15 10, 15
TAMGA0C48 2GN049 2GE049 1600 5, 8, 10, 15, 20, 25 10, 15
TAMGA0C60 2GN064 2GE064 1900 5, 8, 10, 15, 20, 25 10, 15
1 5, 8, and 10 KW Single Phase heaters availble in breaker(BK) or lug(LG)
2 15, 20, and 25 KW Single Phase heaters availble in breaker(BK)
3 10 and 15 KW Three Phase heaters availble in lug (LG)
12/10/10
AIR HANDLER COMPATIBILITY
