2GN SPLIT INSTALLER’S GUIDE
Model GPM
Pressure Drop (psi)
30°F 50°F 70°F 90°F 110°F
026
Full Load
4 0.8 0.7 0.7 0.6 0.6
6 2.4 2.2 2.1 1.9 1.8
8 3.8 3.7 3.5 3.2 3.0
10 5.2 5.0 4.9 4.4 4.2
026
Part Load
3 0.3 0.3 0.3 0.2 0.2
5 1.6 1.5 1.4 1.3 1.2
7 3.0 2.8 2.6 2.4 2.3
9 4.4 4.1 3.8 3.5 3.4
038
Full Load
5 2.5 2.3 2.2 2.0 1.9
7 4.4 4.2 3.9 3.6 3.4
9 6.4 6.0 5.6 5.2 4.8
11 8.3 7.9 7.3 6.8 6.2
038
Part Load
4 1.8 1.7 1.6 1.5 1.4
6 3.4 3.2 3.0 2.8 2.6
8 5.0 4.7 4.4 4.1 3.8
10 6.2 5.6 4.8 4.4 4.0
049
Full Load
6 1.2 1.1 1.0 1.0 0.9
9 2.5 2.4 2.2 2.1 1.9
12 3.9 3.7 3.3 3.2 3.0
15 5.7 5.4 4.9 4.7 4.4
049
Part Load
5 1.0 1.0 0.9 0.8 0.8
8 2.2 2.0 1.9 1.8 1.6
11 3.3 3.1 2.9 2.7 2.5
14 4.9 4.7 4.4 4.0 3.8
064
Full Load
8 1.6 1.7 1.4 1.3 1.2
12 3.6 3.4 3.2 3.0 2.8
16 5.7 5.4 5.0 4.7 4.3
20 8.9 8.6 1.9 7.5 6.9
064
Part Load
6 0.8 0.7 0.7 0.7 0.6
10 2.6 2.5 2.3 2.1 2.0
14 4.4 4.1 3.8 3.6 3.3
18 7.5 7.0 6.5 6.1 5.6
9/5/2012
PRESSURE DROP
Dual Capacity Compressor Resistance Table
MODEL
208-230/60/1
RUN
(OHMS)
START
(OHMS)
026
1.21 - 1.39 1.52 - 1.75
038
0.81 - 0.94 1.41 - 1.63
049
0.48 - 0.55 1.72 - 1.99
064
0.36 - 0.42 1.51 - 1.74
