Trane 2GN Series User Manual

4 18-GL07D1-4
2GN SPLIT INSTALLER’S GUIDE
MODEL NOMENCLATURE
*16HULHV ,QGRRU6SOLW6LQJOH'XDO&DSDFLW\7RQV
PHYSICAL DATA
MODEL 026 038 049 064
COMPRESSOR (1 EACH) DUAL CAPACITY SCROLL
FACTORY CHARGE R410A, OZ [KG]
52
[1.47]
56
[1.59]
90
[2.55]
92
[2.61]
COAX AND WATER PIPING
WATER CONNECTIONS SIZE - SWIVEL- IN [MM] 1 [25.4]
HWG CONNECTION SIZE - SWEAT (I.D.) - IN [MM] 1/2 [12.7]
BRASS SERVICE VALVE - LIQUID LINE - IN [MM]
3/8”
[9.525]
1/2”=
[12.7]
BRASS SERVICE VALVE - SUCTION LINE - IN [MM]
5/8”
[15.875]
3/4”
[19.05]
7/8”
[22.225]
COAX & PIPING WATER VOLUME - GAL [L]
0.7
[2.6]
1.3
[4.9]
1.6
[6.1]
1.6
[6.1]
WEIGHT - OPERATING, LB [KG]
189
[186]
236
[107]
250
[113]
271
[123]
WEIGHT - PACKAGED, LB [KG]
209
[95]
256
[116]
270
[122]
291
[132]
11/05/12
NOTES: All units have TXV expansion devices, and 1/2 in. [12.2 mm] and 3/4 in. [19.1 mm]
electrical knockouts. Brass service valves are sweat type valves.
T 2 G N 049 N N R 1 0 C N *
12345-789101112131415
Model
T – Envirowise
Compressor Type
2 – Dual Capacity
Product Category
G – Geothermal
Product Type
N – Premium Split System
(Interior Grade)
Unit Capacity
MBTU’s
026,038,049,064,072
Discharge Configuration
N – None (Split)
Return Air Configuration
N – None (Split)
Vintage
* - Factory Use Only
Blower Option
N – None (Split)
Coax Option
C – Copper
N – CuproNickel
Hot Water Generation Option
0 – No HWG, No IntelliStart
1 – HWG with Factory Installed Pump,
No IntelliStart
3 – No HWG, IntelliStart
4 – HWG with Factory Installed Pump,
IntelliStart
Voltage
1 – 208-230/60/1
Heating and/or Cooling
R – Heating and Cooling (Reversible)
Rev.: 12/6/2016
