MS-SVN052E-EN 5
Identification
Identification
U-Match Inverter Unit (16 SEER) - R410A Refrigerant Voltage 220/230/1/60hz
Inspection
Upon arrival, the unit should be inspected in search of shipping damages. If these are detected,
they should be indicated on the delivery document presented by the transportation company.
Present the transportation entity a written request for inspection of damages. If further information
should be required, be sure to consult with your local distributor.
Requirements for installation/service of equipment using R410A refrigerant:
• Accessories such as pressure gauge, hoses, refrigerant containers and recovery system must
be designed to handle POE or PVE oils.
• Manifold gauge classification should be 800 PSIG on the high side and 250 PSIG on the low side
with 550 PSIG for restart on the low side.
• All hoses must be classified for 700 PSIG service pressure.
• Leak detectors must be designed to detect R-410A refrigerant.
• Recovery equipment (including containers for refrigerant recovery) must be designed
specifically to handle R-410A refrigerant.
• Do Not use a TXV for R-22.
• Good refrigeration practice requires the installation of a field provided liquid line filter dryer.
See Figure 1.
Outdoor Unit - Cooling Only
Model Capacity
4TYK6524D1000AL 24 MBH - 16 SEER
4TYK6536D1000AL 36 MBH - 16 SEER
4TYK6548D1000AL 48 MBH - 16 SEER
4TYK6560D1000AL 60 MBH - 16 SEER
Outdoor Unit - Heat Pump
Model
Capacity
4TXK6524D1000AL 24 MBH - 16 SEER
4TXK6536D1000AL 36 MBH - 16 SEER
4TXK6548D1000AL 48 MBH - 16 SEER
4TXK6560D1000AL 60 MBH - 16 SEER
