20
18-GF16D1-1B-EN
Figure 14. A4AH4E24A1B60AA
Top Cap
Snap Tab
Feature
Snap Tab
Feature
To
p
Cap
Replace 2 screws
and water diverter
bracket
Remove 2 screws
and water diverter
bracket
Figure 15. A4AH4E30A1B30AA
Top Cap
Snap Tab
Feature
Snap Tab
Feature
Top Cap
Replace 2 screws
and water diverter
bracket
Remove 2 screws
and water diverter
bracket
