18-GF16D1-1B-EN
21
Figure 16. A4AH4E36A1C30AA, A4AH4E42B1C30AA
Snap Tab
Feature
Top Baffle
Assembly
Replace 2 screws
and water diverter
bracket
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
Top Baffle
Assembly
Figure 17. A4AH4E48B1C30AA, A4AH4E60B1C30AA
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
