A4AH6V30A1B30B Airflow Performance with Auxiliary Heat
Airflow Settings
Dip Switch Settings
Nominal Airflow
See following tables for heater application:
- Pressure Drop for Electrical Heaters
- Minimum Heating Airflow Matrix (on unit nameplates)
Switch 7 Switch 8
Low ON ON 601
Med-Lo OFF ON 661
Med-Hi ON OFF 781
High
OFF OFF 973
A4AH6V36A1C30B Airflow Performance with Auxiliary Heat
Airflow Settings
Dip Switch Settings
Nominal Airflow
See following tables for heater application:
- Pressure Drop for Electrical Heaters
- Minimum Heating Airflow Matrix (on unit nameplates)
Switch 7 Switch 8
Low ON ON 696
Med-Lo OFF ON 825
Med-Hi ON OFF 1150
High
OFF OFF 1298
A4AH6V42A1C30B Airflow Performance with Auxiliary Heat
Airflow Settings
Dip Switch Settings
Nominal Airflow
See following tables for heater application:
- Pressure Drop for Electrical Heaters
- Minimum Heating Airflow Matrix (on unit nameplates)
Switch 7 Switch 8
Low ON ON 696
Med-Lo OFF ON 825
Med-Hi ON OFF 1150
High
OFF OFF 1298
A4AH6V48A1C30B Airflow Performance with Auxiliary Heat
Airflow Settings
Dip Switch Settings
Nominal Airflow
See following tables for heater application:
- Pressure Drop for Electrical Heaters
- Minimum Heating Airflow Matrix (on unit nameplates)
Switch 7 Switch 8
Low ON ON 1000
Med-Lo OFF ON 1130
Med-Hi ON OFF 1354
High
OFF OFF 1596
A4AH6V60B1C30A Airflow Performance with Auxiliary Heat
Airflow Settings
Dip Switch Settings
Nominal Airflow
See following tables for heater application:
- Pressure Drop for Electrical Heaters
- Minimum Heating Airflow Matrix (on unit nameplates)
Switch 7 Switch 8
Low ON ON 1000
Med-Lo OFF ON 1130
Med-Hi ON OFF 1354
High
OFF OFF 1596
MMiinniimmuumm AAiirrffllooww CCFFMM
