18-GF14D1-1C-EN
35
Table 24. Downflow (continued)
13. Slide the coil assembly back into the air handler cabinet as shown.
14. Remove the appropriate knock out for the condensate piping.
Figure 14. All models
15. Replace all panels
Figure 15. All models
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
