Figure 24. A4AH6E31, A4AH6V24, A4AH6V30 — Fornt view
Snap
Tab
Feature
Remove 2 screws
and water diverter
bracket
Top Cap
Figure 25. A4AH6E31, A4AH6V24, A4AH6V30 — Fornt view
Snap
Tab
Feature
Replace 2 screws
and water diverter
bracket
Top Cap
Figure 26. A4AH6E31, A4AH6V24, A4AH6V30 — Rear view
Snap
Tab
Feature
Remove 2 screws
and water diverter
bracket
Figure 27. A4AH6E31, A4AH6V24, A4AH6V30 — Rear view
Snap
Tab
Feature
Replace 2 screws
and water diverter
bracket
