20
18-GF81D1-1A-EN
A5AHC005A1D30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208-230 VOLTS
TAP 2 TAP 3 † TAP 4 TAP 5
0.1 1266 1340 1425 1577
0.2 1214 1286 1384 1535
0.3 1163 1242 1335 1494
0.4 1114 1195 1290 1452
0.5 1057 1144 1246 1410
0.6 996 1087 1187 1367
0.7 931 1026 1128 1319
0.8 853 961 1071 1268
0.9 779 889 1005 1211
A5AHC006A1D30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208-230 VOLTS
TAP 2 TAP 3 † TAP 4 TAP 5
0.1 1550 1592 1804 1971
0.2 1511 1550 1767 1939
0.3 1470 1510 1734 1907
0.4 1426 1469 1697 1867
0.5 1379 1424 1656 1839
0.6 1324 1381 1615 1804
0.7 1278 1338 1575 1766
0.8 1229 1292 1536 1722
0.9 1173 1241 1492 1691
• In horizontal and downflow applications, airflow should be limited to 1700 CFM due to condensate blowoff.
A5AHC007A1D30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208-230 VOLTS
TAP 2 TAP 3 † TAP 4 TAP 5
0.1 1574 1648 1781 1935
0.2 1538 1608 1749 1900
0.3 1502 1577 1715 1872
0.4 1466 1542 1685 1842
0.5 1425 1506 1651 1814
0.6 1374 1466 1616 1784
0.7 1328 1423 1576 1749
0.8 1280 1377 1531 1712
0.9 1227 1329 1489 1674
• In horizontal and downflow applications, airflow should be limited to 1800 CFM due to condensate blowoff.
Notes:
• TAP 1 is not an airflow selection. Black wire must always be on TAP 1.
• Values are with wet coil, no filter, and no heaters.
• CFM correction for dry coil = add 3%.
• † = factory setting
