Performance and Electrical Data
A5AHC002A1B30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208-230 VOLTS
TAP 2 TAP 3 † TAP 4 TAP 5
0.1 874 978 1045 1134
0.2 824 934 1002 1096
0.3 746 881 955 1056
0.4 676 813 891 1009
0.5 606 746 828 943
0.6 551 681 762 888
0.7 481 627 702 830
0.8 404 578 653 771
0.9 328 519 606 722
• In horizontal and downflow applications, airflow should be limited to 1000 CFM due to condensate blowoff.
A5AHC003A1B30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208-230 VOLTS
TAP 2 TAP 3 † TAP 4 TAP 5
0.1 886 1027 1094 1196
0.2 844 989 1059 1164
0.3 791 947 1020 1130
0.4 719 896 978 1094
0.5 660 837 926 1053
0.6 584 778 864 1006
0.7 517 723 813 948
0.8 460 650 753 897
0.9 378 594 694 850
• In horizontal and downflow applications, airflow should be limited to 1000 CFM due to condensate blowoff.
A5AHC004A1D30A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208-230 VOLTS
TAP 2 TAP 3 † TAP 4 TAP 5
0.1 1230 1311 1385 1428
0.2 1187 1265 1342 1388
0.3 1140 1220 1299 1345
0.4 1089 1174 1256 1302
0.5 1036 1125 1210 1260
0.6 980 1070 1160 1211
0.7 909 1010 1110 1161
0.8 833 939 1053 1106
0.9 755 904 984 1041
