Trane A951X040BD3SAC - CFM Versus Temperature Rise

22
A951X-SVX001-1D-EN
CFM Versus Temperature Rise
Table 4. Heating Table — Upflow
CFM VS. TEMPERATURE RISE
MODEL
700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300
A951X040BU3SAC 55 48 44 39 36 33 30
A951X060BU4SAC 63 58 52 49 46 43 41 40
A951X080BU4SAC 71 68 64 61 57 54 51 48 45
A951X080CU5SAC 68 65 59 56 54 49 46 44
A951X100CU5SAC 68 65 61 57 55 53 49 46
A951X120CU5SAC 67 65 60 55 54 51 48 44 41
Table 5. Heating Table — Downflow
CFM VS. TEMPERATURE RISE
MODEL
CFM (CUBIC FEET PER MINUTE)
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300
A951X040BD3SAC 57 53 46 45 37 34 31
A951X060BD3SAC 63 58 52 48 44 41
A951X080BD4SAC 72 69 65 62 57 53 49 48
A951X100CD5SAC 68 65 62 58 55 53 50 48 44
A951X120DD5SAC 72 69 66 64 58 56 53 52 49 44
