18-GJ05D1-5
ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
Important: This Document is customer property and is to remain with this unit. Please return to service information
pack upon completion of work.
Important: These instructions do not cover all variations
in systems nor provide for every possible contingency to
be met in connection with the installation. Should further
information be desired or should particular problems
arise which are not covered sufficiently for the pur-
chaser’s purposes, the matter should be referred to your
installing dealer or local distributor.
Note: The manufacturer recommends installing ONLY
AHRI approved, matched indoor and outdoor systems.
Some of the benefits of installing approved matched
indoor and outdoor split systems are maximum efficien-
cy, optimum performance, and the best overall system
reliability.
Note: All AHRI ratings use a 90 second fan off delay.
Use your branded thermostat or separate relay to enable
this delay.
Note: Condensation may occur on the surface of the air
handler when installed in an unconditioned space. When
units are installed in unconditioned spaces, verify that
all electrical and refrigerant line penetrations on the air
handler are sealed completely.
Important: TAM4A0C60S51SB and *AM4A0C60S51SA
air handler applied in downflow or horizontal
configurations should not exceed 2000 CFM. Airflow
above 2000 CFM could result in water blow-off. For
verification, see airflow table.
Important: The TAM4 and AAM4 air handlers will only
use the following internal electric heaters:
BAYEAAC05BK1AA, BAYEAAC05LG1AA,
BAYEAAC08BK1AA, BAYEAAC08LG1AA,
BAYEAAC10BK1AA, BAYEAAC10LG1AA,
BAYEAAC10LG3AA, BAYEABC15BK1AA,
BAYEABC15LG3AA, BAYEABC20BK1AA,
BAYEACC25BK1AA
Convertible Air Handlers
1-1/2 – 5 Ton
TAM4A0A18S11SB
TAM4A0A24S21SB
TAM4A0A30S21SB
TAM4A0A36S31SB
TAM4A0B42S31SB
TAM4A0C48S41SB
TAM4A0C60S51SB
*AM4A0A18S11SA
*AM4A0A24S21SA
*AM4A0A30S21SA
*AM4A0A36S31SA
*AM4A0B42S31SA
*AM4A0C48S41SA
*AM4A0C60S51SA
* May be “A” or “T”
Installer’s Guide
