CLCH-SVX07C-EN 23
Unit Dimensions and Weights
Fans/Motors
Starter/VFD Weights
Fan weights do not include starter/VFD weights. The table below gives approximate starter/VFD
weights.
Motor Weights
Fan weights provided in this manual include the heaviest ODP (open drip-proof) motor.
Table 6. Approximate starter and VFD weights per horsepower (lbs.)
Horsepower 1 1.5 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125
Starter
1
65 65 65 65 65 65 65 65 65 97 97 97 97 97 97 97 97
VFD
2
123 123 132 124 125 136 151 162 177 197 241 325 332 243 258 294 314
Note:
1
These weights represent the largest available starter.
2
VFD weights include transformer, distribution block, and enclosure.
Table 7. Approximate motor weights (pounds)
Motor Type
Motor
RPM
Horsepower
3/4 1 1-1/2 2 3 5 7-1/2 10 15 20 25 30 40 50 60 75 100 125
Energy efficient
ODP (EEOP)
1800 24 29
NEMA Premium
ODP (HEOP)
1200/
6 pole
39 77 91 147 126 249 300 375 443 594 667
NEMA Premium
TEFC (HETC)
56 96 109 148 185 310 341 423 481 614 655
NEMA Premium
ODP (HEOP)
1800/
4 pole
36 42 47 76 82 118 148 234 263 330 379 488 521 698 808 1114 1238
NEMA Premium
TEFC (HETC)
47 54 56 91 108 159 185 285 315 452 481 578 670 808 889 1239 1466
NEMA Premium
ODP (HEOP)
3600/
2 pole
36 36 37 89 104 173 203 267 243 261 407
NEMA Premium
TEFC (HETC)
36 53 62 85 103 154 176 287 322 448 496
