22 CLCH-SVX07C-EN
Unit Dimensions and Weights
Unit size 35 40 50 57 66 80 100 120
Humidifier
-Direct steam
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
544.40 599.28 781.71 897.00 1123.05 1215.33 1362.86 1551.07
-Atmospheric
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
581.42 664.92 723.70 802.82 977.24 1078.41 1264.58 1491.95
Silencer
-3 ft
38.00 38.00 38.00 38.00 38.00 38.00 38.00 38.00
918.37 973.72 1225.82 1331.88 1572.80 1741.00 2195.72 2554.94
-5 ft
62.00 62.00 62.00 62.00 62.00 62.00 62.00 62.00
1334.66 1439.39 1795.06 1944.98 2312.54 2555.39 3230.00 3786.24
2-Deck or 3-Deck Multizone
- Horizontal discharge
78.00 78.00 78.00 n/a n/a n/a n/a n/a
1638.97 1760.51 2002.92 n/a n/a n/a n/a n/a
- Vertical discharge
92.00 92.00 96.00 n/a n/a n/a n/a n/a
1881.25 2021.32 2466.01 n/a n/a n/a n/a n/a
UV light
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
325.48 352.71 394.34 419.43 574.52 604.11 667.60 758.72
Gas heat (highest MBH)
94.00 91.00 100.00 100.00 101.00 101.00 102.00 102.00
2469.40 2560.00 3575.20 3285.90 3700.50 3190.80 4470.00 4426.60
Horizontal end cap
10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00
246.10 267.20 301.30 315.20 429.90 452.10 502.40 565.70
Diagonal economizer for
outdoor unit
75.00 83.00 72.00 75.50 83.00 86.00 93.00 93.00
973.26 1100.52 1168.76 1266.21 1722.26 1919.94 2289.68 2494.18
Exhaust damper section for
outdoor unit
22.40 22.40 22.40 22.40 22.40 22.40 22.40 22.40
351.40 379.60 425.10 443.70 587.70 616.90 681.10 760.20
Hoods
- Side inlet hood (add to width) for
diagonal economizer
27.75 27.75 29.50 33.00 42.63 45.13 47.00 47.00
175.86 195.13 229.85 269.82 316.87 343.85 490.93 566.15
- Side inlet hood (add to width) for
mixing box
34.00 35.00 38.75 43.38 48.63 57.13 60.50 63.00
122.04 128.02 160.97 174.27 189.35 257.94 297.76 330.05
- Back inlet hood (add to length) for
mixing box
27.75 27.75 29.50 33.00 42.63 45.13 47.00 47.00
175.86 195.13 229.85 269.82 316.87 343.85 490.93 566.15
- Exhaust hood (add to length or
width)
34.00 35.00 38.75 43.38 48.63 57.13 60.50 63.00
72.80 76.89 92.81 113.92 128.56 174.08 206.04 221.35
Pipe cabinet weight
15 inches long, 36 inches deep 175.00 175.00 191.00 209.00 215.00 243.00 265.00 265.00
24 inches long, 36 inches deep 199.00 199.00 216.00 236.00 243.00 273.00 298.00 298.00
48 inches long, 36 inches deep 263.00 263.00 284.00 309.00 317.00 354.00 385.00 385.00
96 inches long, 36 inches deep 392.00 392.00 421.00 454.00 466.00 517.00 558.00 558.00
Table 5. Section dimensions (inches) and weights (pounds) - unit sizes 35-120
