Trane AM4A0A30S21SA Series User Manual

CLCH-SVX07C-EN 21
Unit Dimensions and Weights
Unit size 35 40 50 57 66 80 100 120
Coils
-Small horizontal (with 4-row UW)
10.00 10.00 10.00 10.00 n/a n/a n/a n/a
679.61 743.10 915.56 1023.99 n/a n/a n/a n/a
-Medium horizontal (with 8-row UW)
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
1083.29 1208.28 1543.21 1739.24 2183.23 2518.10 3045.45 3584.41
-Extended-medium horizontal
(with 8-row UW)
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
1137.72 1267.13 1595.08 1793.51 2237.43 2574.51 3116.83 3660.64
-Medium-large horizontal
(with 10-row W)
24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50
1944.10 2204.75 2736.01 3195.47 3838.02 4447.61 5453.04 6662.13
-Large horizontal or vertical
(with 10-row W)
48.00 48.00 48.00 48.00 n/a n/a n/a n/a
2140.10 2411.83 2991.25 3459.40 n/a n/a n/a n/a
Fan
6
-Belt-drive plenum fan with motor
53.50 53.50 57.50 59.50 61.00 63.00 73.75 82.25
2311.19 2676.28 3178.70 3496.17 3940.63 4590.36 6035.46 7133.78
-Housed fan (FC/AF/BC) with motor
63.75 63.75 68.50 68.50 84.00 92.00 96.00 96.00
2381.09 2641.30 3148.10 3211.05 4216.56 4980.29 5866.21 6705.45
-Direct-drive plenum fan with motor
55.50 60.00 65.00 65.00 54.75 54.75 54.75 54.75
1648.42 1910.99 2793.74 2851.21 3433.31 3950.32 5356.05 5525.47
Controls section (includes largest
available VFD)
24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50
574.55 596.53 631.20 644.75 782.62 804.08 854.88 920.24
Diffuser
24.50 24.50 24.50 24.50 27.50 37.25 37.25 37.25
365.56 389.25 428.01 445.57 664.01 809.34 876.54 955.28
Discharge plenum
7
-Horizontal
48.00 48.00 48.00 48.00 49.00 54.00 60.00 60.00
474.26 511.01 570.20 594.26 773.17 810.80 891.34 989.20
-Vertical
63.75 63.75 68.50 n/a n/a n/a n/a n/a
779.25 840.96 989.88 n/a n/a n/a n/a n/a
Blender
48.00 48.00 48.00 48.00 49.00 54.00 60.00 60.00
540.76 593.46 675.51 731.75 970.30 1112.23 1345.03 1567.62
Electric Heat
n/a n/a n/a n/a n/a n/a n/a n/a
n/a n/a n/a n/a n/a n/a n/a n/a
Face-and-Bypass Dampers
-Internal face-and-bypass or
face damper only
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
543.64 636.11 713.60 803.86 1026.07 1107.46 1236.82 1361.55
-External face-and-bypass
22.00 22.00 22.00 22.00 39.00 39.00 39.00 39.00
473.39 556.23 630.10 714.61 888.33 973.60 1093.88 1205.53
Energy Wheel
61.25 64.75 64.75 n/a n/a n/a n/a n/a
1497.92 1733.76 1995.01 n/a n/a n/a n/a n/a
CDQ Wheel
56.25 56.25 58.75 n/a n/a n/a n/a n/a
2127.92 2323.76 3275.01 n/a n/a n/a n/a n/a
Integral-face-and-bypass coil
-Less than 4 rows
29.50 29.50 29.50 29.50 29.50 29.50 29.50 29.50
1129.66 1168.40 1793.80 1956.80 2322.61 2378.60 2865.77 2936.42
-4 rows
43.00 43.00 n/a n/a n/a n/a n/a n/a
1681.45 1726.58 n/a n/a n/a n/a n/a n/a
Table 5. Section dimensions (inches) and weights (pounds) - unit sizes 35-120
