Unit Dimensions and Weights
Note: Add 0.19 inches to total unit length for each shipping split to account for gasketing.
Table 4. Section dimensions (inches) and weights (pounds) - unit sizes 3-30
Nominal airflow
1
1500 2,000 3000 4000 5000 6000 7000 8500 10,500 12,500 15,000
Airflow at 625 fpm
2
2169 3475 4338 4581 6075 8331 9025 11,806 13,456 16,944 19,025
Unit size 3 4 6 8 10 12 14 17 21 25 30
Height - indoor unit (in.)
3
29.00 29.00 35.25 37.75 37.75 41.50 41.50 49.00 52.75 61.50 61.50
Height - outdoor unit (in.)
4
includes base drip lip
37.30 37.45 43.70 46.20 46.20 50.33 50.33 57.83 61.58 70.33 70.33
Width (in.)
31.50 44.00 44.00 50.50 61.50 66.50 72.00 72.00 80.00 80.00 93.50
Weight add for outdoor unit
(lbs/in. of unit length)
1.66 1.91 1.91 2.04 2.27 2.40 2.51 2.51 2.67 2.67 2.95
Mixing box
-with or without angled filters
34.00 34.00 34.00 36.00 36.00 36.00 36.00 36.00 34.00 46.00 46.00
192.59 219.00 237.28 277.86 313.45 346.29 365.78 391.36 423.13 539.50 595.82
-with top Traq dampers
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 56.50 56.50
199.73 245.85 265.79 313.60 345.77 381.04 402.17 438.43 527.04 610.12 672.97
-with reduced length for airfoil
dampers only
23.38 23.38 23.38 23.38 23.38 23.38 28.38 28.38 28.38 28.38 32.50
132.81 150.12 164.65 185.54 210.93 231.01 273.01 293.45 326.35 352.21 424.41
Filters
-2-in. or 4-in. angled
24.50 24.50 24.50 26.50 26.50 26.50 26.50 24.50 24.50 24.50 24.50
129.35 155.03 166.86 192.04 215.56 236.22 250.34 286.12 316.30 356.90 398.99
-Cartridge 12-in. or
short bag 18-in.
24.50 24.50 24.50 26.50 26.50 26.50 26.50 24.50 24.50 24.50 24.50
101.83 121.39 130.06 152.86 171.58 192.72 204.20 203.82 222.30 249.79 275.06
-2-in. or 4-in. flat
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00
68.56 82.62 88.08 99.49 111.80 124.66 131.47 136.82 152.24 164.95 183.13
-2-in. and 4-in. combination flat
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
86.42 103.79 110.69 124.26 139.53 161.09 171.37 179.37 198.37 224.08 247.88
-Long bag 30-in.
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 46.00 46.00
133.38 174.65 187.12 219.08 237.62 268.97 283.79 306.36 369.18 379.56 415.84
-Front-load
2-in or 4-in.flat, cartridge or HEPA
40.00 40.00 40.00 40.00 40.00 40.00 40.00 40.00 40.00 40.00 40.00
198.25 220.89 244.19 268.72 292.11 320.14 333.11 370.55 401.66 433.13 470.67
-Front-load Short Bag
45.00 45.00 45.00 45.00 45.00 45.00 45.00 45.00 45.00 45.00 45.00
218.15 242.55 268.05 294.69 320.16 350.45 364.47 404.55 438.50 473.05 513.15
Access or blank
5
-Small horizontal
10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00
48.05 57.43 60.55 66.67 74.92 80.55 84.67 88.41 96.28 100.65 110.78
-Medium horizontal
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00
59.91 71.18 75.25 82.74 92.66 99.61 104.57 109.45 119.10 124.79 136.97
-Extended-medium horizontal
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
74.73 88.37 93.62 102.82 114.83 123.43 129.44 135.74 147.62 154.97 169.71
-Medium-large horizontal
24.50 24.50 24.50 26.50 26.50 26.50 26.50 24.50 24.50 24.50 24.50
111.30 124.41 131.71 154.47 173.94 187.69 197.48 195.61 214.03 225.11 248.63
-Large horizontal or turning
34.00 34.00 34.00 36.00 36.00 36.00 36.00 36.00 34.00 46.00 46.00
145.22 160.85 170.40 196.91 221.19 238.48 250.67 263.28 274.77 369.72 406.60
-Extra-large horizontal or turning
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 56.50 56.50
152.36 187.71 198.92 232.65 253.52 273.22 287.07 310.34 378.68 369.72 406.60
Note:
1
Nominal airflow is based on 500 fpm through a nominal coil (i.e. 500xunit size 8=4000 cfm).
2
Airflow@625 fpm through the flat filter (maximum
filter velocity).
3
Height includes standard 2.5-inch base frame for sizes 3-57 and 6-inch base frame for sizes 66-120.
4
Height includes 6-inch base
frame for sizes 3-120.
5
Variable lengths available from 14-96 inches.
6
Fan section weights include the heaviest fan with the largest ODP motor available.
7
Nominal length and height shown for discharge plenums. Variable plenum height and length is available from 0.5 to 1.5 of nominal.
