Component Installation Requirements
Figure 46. Flat and combination filter placement for unit sizes 57-120
Size 57
20
25
16
20
20
25 25 25 20
1.5
63.33 ft
²
Size 66
20
24
20
20
20
24 24 24 24 16 .5
75.56 ft
²
Size 80
20
16.5
24 24 24 24 24 16 .5
12
20
20
20
85.56 ft
²
Size 100
20
25
20
20
20
20
25 25 25 25 25 .5
104.17 ft
²
Size 120
25
20
25
25
25
20 20 20 20 20 20 20 16 2
122.22 ft
²
