Trane AM4A0A30S21SA Series User Manual

CLCH-SVX07C-EN 67
Component Installation Requirements
Table 15. Side Traq Low-Flow Diagonal Economizer
Unit
size
Damper
dia (in)
Damper
qty
Damper
torque
(in-lb.)
Low flow
Traq torque
(in-lb.)
Remainder
Traq torque
(in-lb.)
Actuator
qty for low
flow Traq
Actuator qty
for remainder
damper
Actuator
total qty
Face to face
linkage
Linkage
on face
4 13.00 2 18.0 18.00 18.00 1 1 2 No No
6 13.00 2 18.0 18.00 18.00 1 1 2 No No
8 13.00 2 18.0 18.00 18.00 1 1 2 No No
10 16.00 2 22.5 22.50 22.50 1 1 2 No No
12 16.00 2 22.5 22.50 22.50 1 1 2 No No
14 16.00 2 22.5 22.50 22.50 1 1 2 No No
17 13.00 4 18.0 18.00 54.00 1 1 2 No Yes
21 20.00 2 33.0 33.00 33.00 1 1 2 No No
25 16.00 4 22.5 22.50 67.50 1 1 2 No Yes
30 20.00 3 33.0 33.00 66.00 1 1 2 No Yes
35 28.00 2 37.5 37.50 37.50 1 1 2 No No
40 28.00 2 37.5 37.50 37.50 1 1 2 No No
50 24.00 3 36.0 36.00 72.00 1 1 2 No Yes
57 24.00 4 36.0 36.00 108.00 1 1 2 No Yes
66 28.00 3 37.5 37.50 75.00 1 1 2 No Yes
80 28.00 4 37.5 37.50 112.50 1 1 2 No Yes
100 28.00 5 37.5 37.50 150.00 1 1 2 No Yes
120 28.00 5 37.5 37.50 150.00 1 1 2 No Yes
Table 16. Side rectangle angle damper - 2000 fpm
Unit size A (in) B (in) Damper qty Torque (in-lb.)
Actuator torque
(max) (in-lb.) Actuator qty Linkage
3 11.25 13.97 1 13.1 42 1 No
4 11.25 13.97 1 13.1 42 1 No
6 15.75 13.97 1 18.3 42 1 No
8 20.25 13.97 1 23.6 42 1 No
10 20.25 16.30 1 27.5 42 1 No
12 27.00 16.30 1 36.7 42 1 No
14 23.25 19.72 1 38.2 42 1 No
17 30.50 19.72 1 50.1 160 1 No
21 36.75 19.72 1 60.4 160 1 No
25 45.75 19.72 1 75.2 160 1 No
30 48.50 20.22 1 81.7 160 1 No
35 45.50 25.47 1 96.6 160 1 No
40 48.00 28.35 1 113.4 160 1 No
50 56.75 31.22 1 147.6 160 1 No
57 65.75 31.22 1 171.1 160 2 No
66 70.50 31.22 1 183.4 160 2 No
80 85.00 31.22 1 221.1 160 2 No
100 95.00 36.97 1 292.7 160 2 No
120 96.00 42.72 1 341.8 160 3 No
