Technical Data
FWD 08 12 20 30 45
Power supply (V/Ph/Hz) 230/1/50
Capacities
Cooling capacity on water (1) (kW) 5,2 8,3 15 18,8 30,1
Heating capacity on water (2) (kW) 6,3 11,9 18,9 20,9 38,2
Fan motor (type) 2 x direct drive centrifugal
Fan power input (3) (kW) 0,23 0,46 0,65 1,04 1,51
Current amps (3) (A) 1,1 2,2 3,1 4,7 5,5
Start-up amps (A) 3,2 5,5 9,3 14,1 16,5
Air flow
minimum (m
3
/h) 490 980 1400 1800 2700
nominal (m
3
/h) 820 1650 2300 3000 4500
maximum (m
3
/h) 980 1970 2600 3600 5400
Main coil
Water entering/leaving connections (type) ISO R7 rotating female
(Dia) 3/4" 3/4" 1 1/2" 1 1/2" 1 1/2"
Electric heater (accessory for blower only)
Electric power supply (V/Ph/Hz) 230/1/50 230/1/50 or 400/3/50 400/3/50 400/3/50 400/3/50
Heating capacity (kW) 2/4 8 10 12 12
Hot water coil (accessory for blower only)
Heating capacity (4) (kW) 6,3 12 17,4 22,4 34,5
G2 filter (filter box accessory)
Quantity 2 2 2 2 2
Dimensions ( LxWxth) (mm) 386x221x8 486x271x8 586x321x8 586*421*8 586*621*8
G4 filter (filter box accessory)
Quantity - 2 2 2 2
Dimensions ( LxWxth) (mm) - 486x264x48 586x314x48 586*414*48 586*614*48
Condensate pump (accessory) (type) Centrifugal
Water flow - lift height (l/h - mm) 24 - 500
Not available for FWD30 and FWD45
Sound level (L/M/H speed)
Sound pressure level (5) (dB(A)) 36/40/43 38/41/44 46/50/53 47/52/57 47/52/58
Sound power level (5) (dB(A)) 46/50/53 48/51/54 56/60/63 57/62/67 57/62/68
Unit dimensions
Width x Depth (mm) 890 x 600 1090 x 710 1290 x 820 1290 x 970 1290 x 1090
Height (mm) 250 300 350 450 650
Shipped unit dimensions
Width x Depth (mm) 933 x 644 1133 x 754 1333 x 864 1333 x 1008 1333*1133
Height (mm) 260 310 360 460 660
Weight (kg) 32 46 61 76 118
Colour galvanised steel
Recommended fuse size
Unit alone (aM/gI) (A) 8/16 8/16 8/16 8/25 8/25
Unit with electric heater (gI) (A) 16 (2kW),25 (4kW) 40 (230V),3*16 (400V) 3*20 3*25 3*25
(1) Conditions: Water entering/leaving temperature: 7/12 °C, Air inlet temperature 27/19°C DB/WB - Nominal air flow
(2) Conditions: Water entering/leaving temperature: 50/45 °C, Air inlet temperature 20°C DB - Nominal air flow
(3) At high speed with nominal air flow.
(4) Water entering/leaving temperature 90/70 °C, air inlet temperature 20 °C DB, Nominal air flow.
(5) A rectangular glass wool duct 1m50 long is placed on the blower.The measurement is taken in the room containing the blower unit.
Heat exchanger operating limits:
FWD:
*water temperature: max 100° C
*absolute service pressure: min 1 bar/max 11 bars
Accessories - Hot water coil:
*water temperature: min. +2° C/max. 100° C
*absolute service pressure: min 1 bar/max 11 bars
AH-SVX03C-GB
Table 4 – Trouble analysis
Symptom(s) Probable Cause(s) Recommanded Action(s)
Any Low Voltage Device not Working Breakpoint Connector
Check Correct Connection
Tighten Connection
Repair Wiring
Dierential Pressure Switch not Working
Tubes not connected Connect Tubes
DPS failed
Blow down Positive Tube and hear click
Replace DPS
Damper not Working
Damper linkage is loose Tighten damper linkage
Damper blade hitting an obstruction Remove obstruction
Damper blade bent Replace damper
Damper actuator is malfunctioning
See symptoms for mixed air damper actuator
not working
Damper actuator not working 24 VAC power
supply not present at the actuator
Control transformer furnishing the damper
actuator 24 VAC has failed
Check transformer
24 VAC power wiring is broken or shorted Repair wiring
Damper actuator not working. 0 to 10 VDC
input signal to acuator not present
0 to 10 VDC input signal wiring broken
or shorted
Repair wiring
Valve not working
Valve not piped per recommended ow
arrangement
Re-pipe valve to recommended ow
arrangement
Valve seat hitting an obstruction in pipe Remove obstruction
Valve actuator is malfunctioning
See symptoms for valve actuator
not working
Valve actuator not working. 24 VAC power
supply not present at the actuator
Control transformer furnishing the cooling
valve actuator 24 VAC power has failed
Check transformer
24 VAC power wiring broken or shorted Repair wiring
Valve actuator not working. 0 to 10 VDC
input signal to actuator not present
0 to 10 VDC input signal wiring broken
or shorted
Repair wiring
Factory engineered controls
