ASHRAE Guideline 3 Report
Information Manual 9
Condenser Water Flow
The following will be displayed only if the Differential
Water Sensing Option is installed.
The possible values for units are “gpm” or “lpm.”
Condenser Water Flow Switch Status
The following screen is displayed only if the
Differential Water Pressure Sensor Option is not
Installed. This screen displays the status of the
condenser water flow switch status at the input to the
UCM.
Possible values for [y] are Flow Switch is Open/No
Flow or Flow Switch is Closed/Flow
Aux. Bundle or Heat Recovery Temps
The following will be displayed only if either the Heat
Recovery Option or Aux Condenser Option is
installed.
Approx Condenser Water Flow: xxx.x gpm/lpm
Press (Next)(Previous) To Continue
Condenser Water Flow Switch Status:
[y]
Aux/Heat Rcvy Ent Wtr Temp: xxx.x f/c
Aux/Heat Rcvy Lvg Wtr Temp: xxx.x f/c
