Field Start-up
40 CVHE-CLD-1A
Evap Leaving Water Temp Offset
Possible values of [setting] are: -2.0°F to 2.0°F in
0.1°F increments (-/+ 1.1°C in 0.1°C increments).
Factory Default is 0.0°F.
Saturated Evap Rfgt Temp Offset
Possible values of [setting] are: -2.0°F to 2.0°F in
0.1°F increments (-/+ 1.1°C in 0.1°C increments).
Factory Default is 0.0°F.
Water Pressure Calibration
The following menus is displayed only if the “Diff Wtr
Press Sensor” setpoint is set to “Installed, <= 150
psig.”
Possible values of [setting] are: Auto (Factory
Default) and Manual
If the above menu is set to “Manual,” the following
two menus are displayed.
Possible values is 0 to 25 psid (0 to 172.4 kPa) in 0.1
psid (kPa) increments. Factory Default is 0.0 psid
(kPa).
Possible values is 0 to 25 psid (0 to 172.4 kPa) in 0.1
psid (kPa) increments. Factory Default is 0.0 psid
(kPa).
The value displayed in the preceding two menus
shall normally be 0.0 psid (kPa). When a manual
calibration of the evaporator or condenser water
pressure is desired, the measured differential
pressure shall be entered in the appropriate menu.
This non-zero value shall return to 0.0 psid (kPa)
when the water pressure calibration is completed.
Evap Leaving Water Temp Offset:[setting]
Press (+)(-) to Change Setting
Saturated Evap Rfgt Temp Offset: [setting]
Press (+)(-) to Change Setting
Water Pressure Calibration: [setting]
Press (+)(-) to Change Setting
Measured Evap Diff Wtr Press: X.X PSID/kPa
Press (+)(-) to Change Setting
Measured Cond Diff Wtr Press: X.X PSID/kPa
Press (+)(-) to Change Setting
To Next Page
