AFDH-SVN01A-EN 29
AFDH Drive Package Specifications
Table 8. Custom enclosure parts; D-Frame 443 amp model drives
Trane Assembly Part Numbers for all Optional Model Versions of
D-Frame 443 Amp AFDH
UCP2 020600310100 020600310200 020600310300
CH531/
AdaptiView
020600380100 020600380200 020600380300
Figure 12
Callout
Part Description
Trane X-Code
Part #
Mnemonic #
(If available)
Quantity Quantity Quantity
3
4 KVA Transformer X13580273010 TRR01404 1 1 1
4
Circuit breaker handle X32070764010 1 1 1
5
Circuit breaker cable X19070649010 1 1 1
6
Circuit breaker mechanism X14080863010 1 1 1
7
Circuit breaker X13050837010 1 1 1
8
Ground lug X19150083010 LUG00100 1 1 1
9
Choke X13641086010 1 1 1
No #
Choke mounting bracket 506898810100 1 1 1
10
Current transformer 185 - 267 amps X13580269040 TRR02030 3
Current transformer 268 - 334 amps X13580269050 TRR02031 3
Current transformer 335 - 467 amps X13580269060 TRR01142 3
13
Fuse Holder; 3-Pole X13110658070 HLD00219 1 1 1
14
Fuse 15 amps X13110430220 FUS00897 2 2 2
15
Fuse 2 amps X13110430110 FUS01017 1 1 1
16
Potential Transformer X13590079010 TRR00713 3 3 3
