Trane CVHF Installation

AFDH-SVN01A-EN 31
AFDH Drive Package Specifications
Table 11. Custom enclosure parts; E-Frame 678 amp model drives
Table 12. Custom enclosure parts; E-Frame 730 amp model drives
Trane Assembly Part Numbers for all Optional Model Versions of
E-Frame 678 Amp AFDH
UCP2 020600340100 020600340200
CH531/
AdaptiView
020600410100 020600410200
Figure 12
Callout
Part Description X-Code Part #
Mnemonic #
(If available)
Quantity Quantity
3
4 KVA Transformer X13580273010 TRR01404 1 1
4
Circuit breaker handle X32070764010 1 1
5
Circuit breaker cable X19070649010 1 1
6
Circuit breaker mechanism X14080863010 1 1
7
Circuit breaker X13050839010 1 1
8
Ground lug X19150083010 LUG00100 1 1
9
Choke X13641087010 1 1
No #
Choke mounting bracket 506898810200 1 1
10
Current transformer 335 - 467 amps X13580269060 TRR01142 3
Current transformer 468 - 667 amps X13580269070 TRR01255 3
13
Fuse Holder; 3 Pole X13110658070 HLD00219 1 1
14
Fuse 20 amps 656412821000 FUS01895 2 2
15
Fuse 2 amps X13110430110 FUS01017 1 1
16
Potential Transformer X13590079010 TRR00713 3 3
Trane Assembly Part Numbers for all Optional Model Versions of
E-Frame 730 Amp AFDH
UCP2 020600350100 020600350200 020600350300
CH531/
AdaptiView
020600420100 020600420200 020600420300
Figure 12
Callout
Part Description
Trane X-Code
Part #
Mnemonic #
(If available)
Quantity Quantity Quantity
3
4 KVA Transformer X13580273010 TRR01404 1 1 1
4
Circuit breaker handle X32070764010 1 1 1
5
Circuit breaker cable X19070649010 1 1 1
6
Circuit breaker mechanism X14080863010 1 1 1
7
Circuit breaker X13050839010 1 1 1
8
Ground lug X19150083010 LUG00100 1 1 1
9
Choke X13641087010 1 1 1
No #
Choke mounting bracket 506898810200 1 1 1
10
Current transformer 335 - 467 amps X13580269060 TRR01142 3
Current transformer 468 - 667 amps X13580269070 TRR01255 3
Current transformer 668 - 1000 amps X13580269080 TRR01405 3
13
Fuse Holder; 3 Pole X13110658070 HLD00219 1 1 1
14
Fuse 20 amps 656412821000 FUS01895 2 2 2
15
Fuse 2 amps X13110430110 FUS01017 1 1 1
16
Potential Transformer X13590079010 TRR00713 3 3 3
