Trane CVHG Installation Instructions

AFDH-SVN03H-EN 45
Startup Test Log
Water-Cooled CenTraVac Chiller with Tracer AdaptiView Control and
Adjustable Frequency Drive (AFD) Starter
Job Name AFD Serial Number
Job Location AFD Model Number
Sales Order Number Ship Date
Chiller Serial Number Start Date
Chiller Model Number
Starter Date: Tracer TU: Service Setpoints View: AFD Default Setting
Manufacture AFD Control Auto
Type Re-Optimization Sensitivity 20%
Vender ID
Model Number
UC800 Starter Type: Unit Mount AFD
Tracer TU: Configuration View: Starter
Trane
Default
Setting
Volts and Hz
Amps Restart Inhibit Stop to Start Time 30
Motor Data: Surge Protection enable
Manufacturer Surge Sensitivity 20
Type and Frame Power Loss Reset Time 60
Drawing # Unit Line Voltage *
Serial Number Motor NP RLA *
Nameplate Data: CT Meter Scale 0
RLA Stop Delay 3
KW Voltage Transformer Ratio 20
Volts and Hz Stator Resistance *
Prestart Checks Date Checked Current Unbalance Trip Point 30
Drive Grounded Acceleration Time 30
Motor Rotation Acceleration Shutdown Action Shutdown
Drive Chassis Grounded Overload Type Linear
Control Wiring Tight Phase Reversal Enable
Drive Connections are Tight Contactor Integrity Disable
Verified Settings Phase Reversal Grace Period 700
Surge Protection Enable
Comments: Momentary Power Loss 2000
Restart Inhibit Stop to Start 30
Surge Sensitivity 20
Power Loss Reset 15
RTD Type 75
*Must be set per sales order variable.
Test Log Date: Log 1 Log 2
AFD Output Power (KW)
Speed
Frequency
Tracer TU Field Startup View: AFD
Maximum Frequency 60
Minimum Frequency 38
AFD Surge Capacity Increase 1
Tracer TU Status View: Motor
Average Line Current
Starter Average Phase Voltage
Starter Load Power Factor
Motor Winding #1 temp
Motor Winding #2 temp
Motor Winding #3 temp
