20
CVHE-SVX02M-EN
Table 4. Representative weights, 60 Hz chillers (kg) (continued)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
1070–1300 1062 250E 250L 34542 28726 35903 30087
1470 1340 210L 210L 29279 24757 30640 26118
1470–1720 1340 142L 210L 26755 22508 28115 23868
1470–1720 1340 250E 250L 35744 29928 37105 31289
Notes:
1. TECU tubes, 0.71 mm tube wall thickness.
2. 2068.4 kPaG non-marine waterboxes.
3. Heaviest possible bundle and motor combination.
4. Operating weights assume the largest possible refrigerant charge.
5. Weights with starters assume the heaviest possible starter (AFD when it’s an allowed option).
6. Industrial Control Panel (INDP) option, add 23 kg.
7. Control Power Transformer (CPTR) option, add 59 kg.
8. Supplemental Motor Protection (SMP) option, add 227 kg.
Table 5. Weights, 50 Hz chillers (kg)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
CVHE
190–320
215
032S 032S
6706 6090 — —
231 — — 7464 6848
190–320
215
032S 032L
6981 6296 — —
231 — — 7739 7054
190–320
215
032L 032L
7364 6591 — —
231 — — 8122 7349
190–320
215
050S 050S
8934 7800 — —
231 — — 9715 8581
190–320
215
050S 050L
9395 8143 — —
231 — — 10176 8924
190–320
215
050L 050L
9901 8474 — —
231 — — 10721 9300
300–500
360
050S 050S
9665 8530 — —
379 — — 10255 9120
300–500
360
050S 050L
10126 8874 — —
379 — — 10716 9464
300–500
360
050L 050L
10670 9249 — —
379 — — 11260 9839
300–500
360
050S 080S
11305 9793 — —
379 — — 11895 10383
300–500
360
080S 080S
13943 12029 — —
379 — — 14534 12619
300–500
360
080S 080L
14664 12611 — —
379 — — 15254 13201
300–500
360
080L 080L
15580 13254 — —
379 — — 16171 13844
CVHG
480–565 489 050S 050S 10096 8957 10349 9210
480–565 489 050S 050L 10557 9300 10810 9553
480–565 489 050L 050L 11064 9636 11316 9889
UUnniitt CClleeaarraanncceess aanndd WWeeiigghhttss
